VSC63014 : VSC63014 short cased axial flow extract fan replaces ZSC630-41
Business , Catering , Commercial , Systemair , Vent-Axia , Ziehl-Abegg , Extractor Fans , Short Cased Axials / (VSC63014)
| Code & Description | Price | |
|---|---|---|
|
VSC63014 : VSC63014 short cased axial flow extract fan replaces ZSC630-41
Note: £779.00 + VAT for new customers using 'WELCNFAN1' discount code!
|
£916.47 + VAT £1,099.76 | |
We accept :
Manufactured by Ziehl Abegg and distributed by Vent Axia and Systemair, this is one of the most popular short cased axial on the market today. This fan has a sickle blade and offers improved performance over the aerofoil blade. Ziehl Abegg are one of, if not the biggest external rotor motor manufacturers in the world, they have over 100 years of engineering experience behind them, which gives you the confidence. If a low cost painted finish fan is your choice this is among the best available.
Supplied fully assembled
Fully speed controllable
Can be used in any non hazardous environment
Suitable to run in temperatures from ‑40°C to up to 70°C in some instances
Low to medium air volumes
Low to medium static pressures
Available sizes 315mm – 630mm 1ph from stock
Tough epoxy paint finish
Die cast aluminium impellers (the bit that goes around)
Motor class F insulation with protection to IP54
1.75KW
230V Single Phase
7.7amps Full Load Current
21.00amps Starting Current
15% discount with code ‘welcnfan1’
Note: Code can only be used once per customer. Discount codes are entered after selecting shipping method.
Need today? We offer same day delivery
Same day deliveries locally & nationwide (UK mainland only). Price on request — Send message with order, or call 0161 864 1777.
