Powerbox 3 ‑50- 315 – 1 — PB315140 Woods Air Movement
Flakt Woods
Prices & Options
New for 2023 the evolution of the Powerbox to the all New Powerbox 3 from Woods Air Movement. 5 x Single phase models, via a single phase in and three phase out inverter speed controller, sizes 315mm to 500mm. Afurther 2 x sizes at 560mm and 630mm in three phase only and suitable for Inverter speed control. Constructed is using a Pentapost frame. Each unit comes with 4 panels, all of which can be removed and relocated to give multiple outlet orientations at either 90 degrees to the inlet or 180 degrees for straight through air movement.
7 Model Sizes
Volumes Up to 4.7 m³/s (16,920 m³/h)
Pressures Up to 1100 Pa (Static)
Impeller Backward Curved Impeller
Case Style Aluminium Penta-post Frame
Case Coating Pregalvanised Sheet Steel
Case Insulation Double Skinned 20mm Fiberglass
Installation Horizontal or Vertical
Location Internal or External with Cowl
IP rating IP54
Temperature Up to 50°C
| Code & Description | Price | |
|---|---|---|
| PB315140 : Powerbox 3 -50- 315-1 - PB315140 Woods Air Movement | £914.45 + VAT £1,097.34 | |
We accept :
15% discount with code ‘welcnfan1’
Note: Code can only be used once per customer. Discount codes are entered after selecting shipping method.
Need it today? We offer same day deliveries
Same day deliveries locally & nationwide (UK mainland only). Price on request — Send message with your order, or call 0161 864 1777.
